OKTAV S

Timeless and functional cabinet design together with high quality components produce a dynamic sound that fits pretty much everywhere.

  • Height: 35cm

  • Width: 18.5cm

  • Depth: 8cm

  • Net weight (each): 2 kg

  • Speaker type: 2-Way Passive

  • Sensitivity: 85.6dB 2.83V/1m

  • Impedance: 4Ω

  • Frequency Response: 85Hz – 25kHz (±3dB)

Cabinet Features

Precision-cut speaker body

Proprietary internal sound dissipation pattern

Maximum strength and rigidity thanks to shape

Components

Our clever design is based around “time alignment”, where driving componets are vertically aliged, ensuring that all frequencies arrive at your ears simultaneously.

  • The main 3.5 inch (89mm) driver features a low distortion, full-range performance of 65 Hz to (a limited) 4K kHz. It is equipped with a rubber-edged, anodised aluminum alloy cone for maximum durability and large excursion capability, exactly what you need for low distortion at higher volumes.

  • The main 0.5 inch (13mm) tweeter adds a great top-end sparkle to an overall balanced and detailed sound profile.

  • Using a precisely tuned and weighted passive radiator in a small enclosure is a great way to increase bass performance. The potential of this 4 inch (102mm) aluminium cone passive is massive, and an ideal solution for delivering remarkable performance at this size.

  • The crossovers feature premium components and split the frequency between the main driver and the tweeter using a 2nd order Linkwitz-Riley (12dB/octave) schematic. All components are securely fastened to a printed circuit board (PCB) for extra protection from short circuits and vibration.

Limited Collection.
